CleanTech® 500EZ Wall-Mounted Industrial Hand Washing Station

CleanTech^® Overview

Designed for high–use areas
Wall mount
Washes up to mid–forearm
Stainless steel body, NEMA 4X electronics housing
Solution empty indicator
CIP Friendly
Visible Compliance Monitor

What are CleanTech^®Automatic Hand Washer Stations?

CleanTech^® Specifications

Dimensions: 18 1/8” width x 19 5/8” depth x 28 3/4” height
Weight: 76 lbs.
Shipping Weight: 93 lbs.
Cycle Activation: Automatic, via infrared photo-optical sensor. 12-second wash and rinse cycle.
Hand Wash Compliance Monitor: Counts number of handwash cycles. Optional resettable counter.
LED light bar solutions level indicator
Water Consumption: 0.6 gallons per 12-second hand wash cycle
Electrical: 100-240 VAC 50/60 Hz, 160 W
Plumbing Inlet: 2 each, 3/4" male hose, hot and cold minimum 4 GPM, 40-100 PSI, 50 PSI optimum, water supply line supplied
Drain: Standard 1 1/2" drain stub, P–Trap to be supplied by facility. Ideal drain height 18" from floor.
Solutions Storage: one 2 1/2 gallon container of hand hygiene solution
Solutions Compatibility: Required solution provided by Meritech (Other solutions will void warranty.) Holds one, 2.5 gallon container of UltraPure Hand Hygiene Solution, which provides up to 1,750 washes in high volume areas.

Full Specifications:

500EZ Spec Preview

CleanTech^® Enhancements

500EZ-New-FP-1

Integrated Air Curtain

Need Help with Your 500EZ Automatic Hand Washer Station?

Get help from our CleanTech^® service team using the button here.

CleanTech^® Plus Program Includes:

Ownership of CleanTech^® Automatic Hand Washer Station
All required Meritech Hygiene Solutions
Regular preventative maintenance, deep cleaning, calibration, and training
Expert hygiene consultation and implementation
Full parts and labor warranty
Free shipping
No up-front cost
Receive the newest CleanTech^® equipment every 3 years

What is CleanTech®Plus?:
